Applications
High ways, primary streets, through ways, secondary streets. Driver ways, resident areas, parking lots, gardens and so on.
Features
• Module optical lens design that enhance the heat pin performance of the fixture.
• Stronger body with high pressure die-cast aluminium alloy housing with less weight ensures Impact grade reaches >IK08
• High efficiency coatings, paint and metal parts successfully pass 600 hours salt spray test.
• High transparent optical lens and Tempered glass, different types lens for choice.
• With surge protector lamp can reach Class II (10KV) or Class II.
• Enough space for installing more devices like Zigbee controller / wireless control system to establish smart city operation for energy conservation and environmental protection.
Specification
Product Code | MTLD006A | MTLD006A | MTLD006B | MTLD006B |
Rated Power | 60W | 80W | 100W | 120W |
CCT | 3000K-6500K | 3000K-6500K | 3000K-6500K | 3000K-6500K |
Luminous Flux | 120LM/W | 120LM/W | 120LM/W | 120LM/W |
Installation Diameter | 50mm 60mm | 50mm 60mm | 60mm | 60mm |
N.W./G.W. | 4.2KGS/5KGS | 4.3KGS/5.1KGS | 5.4KGS/6.4KGS | 5.5KGS/6.5KGS |
Product Size | 555-250,110 | 555-250*110 | 670*275-110 | 670*275*110 |
Packing Size | 630*300*150 | 630*300*150 | 725*300*150 | 725*300*150 |
