Applications
High ways, primary streets, through ways, secondary streets. Driver ways, resident areas, parking lots, gardens and so on.
Features
• Modern fashion design of appearance, excellent self-cleaning capability.
• Used in high strength aluminum die casting material, surface anti-ageing electrostatic spray process, super resistance to corrosion.
• High transparent optical lens and Tempered glass.
• Horizontal installation: +10°~ -^adjustable;
• Vertical installation: +10°~ -10°adjustable.
• Different types lens for choice.
• IK08
Specification
Product Code | MTLD003A | MTLD003B | MTLD003B | MTLD003C | MTLD003C | MTLD003D | MTLD003D |
Rated Power | 30W | 40W | 80W | 100W | 150W | 180W | 200W |
CCT | 3000K-6500K | 3000K-6500K | 3000K-6500K | 3000K-6500K | 3000K-6500K | 3000K-6500K | 3000K-6500K |
Luminous Flux | 110LM/W | 110LM/W | 110LM/W | 110LM/W | 110LMAV | 110LM/W | 110LM/W |
Installation Diameter | 60mm | 60mm | 60mm | 60mm | 60mm | 60mm | 60mm |
N.W./G.W. | 3.5KGS/4.3KGS | 4.7KGS/5.6KGS | 4.7KGS/5.6KGS | 6.4KGS/7.8KGS | 6.4KGS/7.8KGS | 10.4KGS/11.5KGS | 10.4KGS/11.5KGS |
Product Size | 507*210* 130 | 616*259*186 | 616*259* 186 | 677*305* 187 | 677*305*187 | 850*366*198 | 850*366*198 |
Packing Size | 570*246*140 | 680*295"150 | 680*295*150 | 750*355*165 | 750*355*165 | 910*425*195 | 910*425"195 |
Applications
High ways, primary streets, through ways, secondary streets. Driver ways, resident areas, parking lots, gardens and so on.
Features
• Modern fashion design of appearance, excellent self-cleaning capability.
• Used in high strength aluminum die casting material, surface anti-ageing electrostatic spray process, super resistance to corrosion.
• High transparent optical lens and Tempered glass.
• Horizontal installation: +10°~ -^adjustable;
• Vertical installation: +10°~ -10°adjustable.
• Different types lens for choice.
• IK08
Specification
Product Code | MTLD003A | MTLD003B | MTLD003B | MTLD003C | MTLD003C | MTLD003D | MTLD003D |
Rated Power | 30W | 40W | 80W | 100W | 150W | 180W | 200W |
CCT | 3000K-6500K | 3000K-6500K | 3000K-6500K | 3000K-6500K | 3000K-6500K | 3000K-6500K | 3000K-6500K |
Luminous Flux | 110LM/W | 110LM/W | 110LM/W | 110LM/W | 110LMAV | 110LM/W | 110LM/W |
Installation Diameter | 60mm | 60mm | 60mm | 60mm | 60mm | 60mm | 60mm |
N.W./G.W. | 3.5KGS/4.3KGS | 4.7KGS/5.6KGS | 4.7KGS/5.6KGS | 6.4KGS/7.8KGS | 6.4KGS/7.8KGS | 10.4KGS/11.5KGS | 10.4KGS/11.5KGS |
Product Size | 507*210* 130 | 616*259*186 | 616*259* 186 | 677*305* 187 | 677*305*187 | 850*366*198 | 850*366*198 |
Packing Size | 570*246*140 | 680*295"150 | 680*295*150 | 750*355*165 | 750*355*165 | 910*425*195 | 910*425"195 |
