MTLD-048
MT-LIGHTING
940599
MT-LIGHTING（Yangzhou M.T. New Energy & Lighting Group Co., Ltd.）
Applications：
High ways, primary streets, through ways, secondary streets. Driver ways, resident areas, parking lots, gardens and so on.
Features：
• Modern fashion design of appearance, excellent self cleaning capability.
• Used in high strength aluminum die casting material, surface anti-ageing electrostatic spray process, super resistance to corrosion.
• High transparent opt记al lens and Tempered glass.
• Horizontal installation: +10°~ -10cadjustable;
• Vertical installation: +10°~ -10*adjustable.
• Different types lens for choice.
•IK08
Specification：
Product Code | MTLD048A | MTLD048B | MTLD048C | MTLD048D | MTLD048E |
Rated Power | 60W | 80W | 120W | 150W | 200W |
CCT | 3000K-6500K | 3000K-6500K | 3000K-6500K | 3000K-6500K | 3000K-6500K |
Luminous Flux | 130LM/W | 130LMM | 130LM/W | 130LM/W | 130LM/W |
Installation Diameter | 48mm | 60mm | 60mfn | 60mm | 60mm |
N.W./G.W. | 3.3KGS/3.8KGS | 3.5KGS/4KGS | 5.2KGS/6KGS | 5.5KGS/6.2KGS | 5.5KGS/6.2KGS |
Product Size | 523*199-135 | 600-245-155 | 636*290*155 | 686*290-155 | 755-310-155 |
Packing Size | 575*225*125 | 660*270*135 | 685*310*140 | 735*310*140 | 815*330*150 |
